AP22A6-AABN - Betts - Manifold Air Control Panel for 6 Compartments - LJI Part: AP22A6-AABN
SKU
AP22A6-AABN
SKU
AP22A6-AABN
$1,196.83
| Brand | : Betts |
|---|---|
| Type | : Air Valve Control Panel |
| Material | : Aluminum |
| Vendor Number | : AP22A6-AABN |
Short Description:
This Manifold Air Control Panel from Betts is a Style A design for 6 Compartment tanks. It is made from lightweight anodized aluminum that resists corrosion and has a Buna-N seal. Also, it is a Push/Pull design that features a reset function in addition to a pressure gauge and indicator.
Details
- Max Air Pressure:150 PSI Temperature Range:-40F to 160F
- Manifold controls pneumatic components like Vapor Valves and Internal Self-closing Stop Valves
- Plug and Play Assembly combines Master Control Valve with Distributor Valves for easy setup
- Panel Style ?A? Features includes Pressure Gauge and Indicator Wink for visual pressure indication and verification
- Reset Function retracts all Distributor Valves to closed position when pushed in
- Dual Air Manifold System can be used with additional shuttle valves for tank trucks with dual pump systems, preventing cross-contamination
- Made from anodized aluminum for corrosion resistance and performance
