T3214MP250100PM - Dixon 2- 1/2 x 1" - BioPharm Clamp x Clamp Eccentric Reducer Stainless Steel - LJI Part: T3214MP250100PM
SKU
T3214MP250100PM
SKU
T3214MP250100PM
$200.12
| Brand | : Dixon |
|---|---|
| Type | : Eccentric Reducers |
| Vendor Number | : T3214MP250100PM |
High purity eccentric reducer, 2-1/2" to 1" tube OD, clamp x clamp. Built to the ASME BPE standard with a PM finish, SF4 and full material traceability.
Dixon's Bradford High Purity BioPharm line covers the fittings that have to be certified rather than merely clean. Here that means a 2-1/2" x 1" eccentric reducer, clamp x clamp, finished to PM.
- Size: 2-1/2" x 1" tube OD
- Material: 316L stainless steel, controlled sulphur to meet orbital welding specifications
- Surface finish: PM finish, SF4
- Manufactured to the latest edition of the ASME BPE International Standard, Bioprocessing Equipment
- Meets 3-A Sanitary Standards for Sanitary Fittings, Number 63-03 (authorization number 621)
- End connections: clamp x clamp
- Marked with job number, 316L, part number, heat number, surface finish code and ASME BPE
- Material test report (MTR) included and traceable through the job number
- PM fittings are capped in white to prevent damage and contamination
