CF1200310 - PT Coupling 1 inch Part C x 1 inch hose Shank Brass C-Coupler - LJI Part: CF1200310
SKU
CF1200310
SKU
CF1200310
$21.35
| Brand | : Pt Coupling |
|---|---|
| Size | : 1 Inch |
| Type | : Part C |
| Material | : Brass |
| Vendor Number | : CF1200310 |
Connects coupler x hose shank in 1". Brass construction from PT Coupling, cast and machined in the USA.
A coupler x hose shank connection in 1", made and broken by hand. The multi-barbed shank takes a center punch clamp or an interlocked ferrule or sleeve. Brass gives useful corrosion resistance without the price of stainless.
- Size: 1"
- Type: Part C coupler
- Connection: coupler x hose shank
- Material: brass
- Maximum allowable working pressure: 250 psi
- Pressure rating is based on Buna-N seals below 100°F
- Multi-barbed hose shank works with center punch clamps or an interlocked ferrule or sleeve
- Cast, machined and assembled in the USA
- Assembled with solid pins
- Complies with Commercial Item Description A-A-59326D for quick disconnect couplings
- Not rated for compressed gas service, including air and steam
