CF1200520 - PT Coupling 2 inch Part E x 2 inch hose Shank Brass E-Adapter - LJI Part: CF1200520
SKU
CF1200520
SKU
CF1200520
$41.40
| Brand | : Pt Coupling |
|---|---|
| Size | : 2 Inch |
| Type | : Part E |
| Material | : Brass |
| Vendor Number | : CF1200520 |
PT Coupling Part E adapter, 2", brass. Makes and breaks a adapter x hose shank connection by hand. Rated to 250 psi at this size.
The part e adapter is the adapter x hose shank half of a cam and groove pair. In 2" and brass, it covers most of what a transfer line asks for. The multi-barbed shank takes a center punch clamp or an interlocked ferrule or sleeve.
- Size: 2"
- Type: Part E adapter
- Connection: adapter x hose shank
- Material: brass
- Maximum allowable working pressure: 250 psi
- Pressure rating is based on Buna-N seals below 100°F
- Multi-barbed hose shank works with center punch clamps or an interlocked ferrule or sleeve
- Cast, machined and assembled in the USA
- Assembled with solid pins
- Complies with Commercial Item Description A-A-59326D for quick disconnect couplings
- Not rated for compressed gas service, including air and steam
