2770207 - PT Coupling 3/4 inch Part B x 3/4 inch MNPT Food-Grade Polypropylene B-Coupler - LJI Part: 2770207
SKU
2770207
SKU
2770207
$15.80
| Brand | : Pt Coupling |
|---|---|
| Size | : 3/4 Inch |
| Type | : Part B |
| Material | : Polypropylene |
| Vendor Number | : 2770207 |
Short Description:
The PT Coupling Coupler is designed to provide a secure and reliable connection for food-grade applications. It features a Type B connection with 3/4 inch size on both ends with one end having a male NPT thread for easy installation. Constructed from food-grade polypropylene in a white color this coupler is suitable for use in food and beverage industries ensuring that it meets strict safety and hygiene standards. With dimensions of 0.78 inches ID 2.11 inches OD and 2.1 inches in length it provides a leak-free and contamination-free connection between hoses or pipes. The maximum operating pressure for this coupler is 100 psi making it suitable for low-pressure applications in food processing and handling. It comes with additional information including an exposed length of 1-1/4 inches and an extended OD of the cam arms up to 4.51 inches ensuring ease of use during operations.
This PT Coupling part is proudly made in the USA.
Details
- Weight: 0.158 pounds
- Body Material: Food-Grade Polypropylene
- Color: White
- Maximum Operating Pressure: 100 psi
- Inner Diameter (ID): 0.78 inches
- Outer Diameter (OD): 2.11 inches
- Overall Length (OAL): 2.1 inches
- Exposed Length (EL): 1.25 inches
- Extended Cam Arms Diameter: 4.51 inches
- Connection 1: 0.75-inch Type B
- Connection 2: 0.75-inch MNPT
- Cam Arms: HBS 300 Series Stainless Steel
