CF1000507 - PT Coupling 3/4 inch Part E x 3/4 inch hose Shank Aluminum E-Adapter - LJI Part: CF1000507
SKU
CF1000507
SKU
CF1000507
$2.24
| Brand | : Pt Coupling |
|---|---|
| Size | : 3/4 Inch |
| Type | : Part E |
| Material | : Aluminum |
| Vendor Number | : CF1000507 |
3/4" Part E adapter in aluminum, connecting adapter x hose shank. Rated to 250 psi at this size. Made in the USA.
Aluminum is light and economical with good abrasion resistance and fair corrosion resistance, which covers water, hydraulic oil, coolants, gasoline and petroleum. This 3/4" part e adapter connects adapter x hose shank. The multi-barbed shank takes a center punch clamp or an interlocked ferrule or sleeve.
- Size: 3/4"
- Type: Part E adapter
- Connection: adapter x hose shank
- Material: aluminum
- Maximum allowable working pressure: 250 psi
- Pressure rating is based on Buna-N seals below 100°F
- Multi-barbed hose shank works with center punch clamps or an interlocked ferrule or sleeve
- Cast, machined and assembled in the USA
- Assembled with solid pins
- Complies with Commercial Item Description A-A-59326D for quick disconnect couplings
- Not rated for compressed gas service, including air and steam
