CF1200330 - PT Coupling 3 inch Part C x 3 inch hose Shank Brass C-Coupler - LJI Part: CF1200330
SKU
CF1200330
SKU
CF1200330
$63.89
| Brand | : Pt Coupling |
|---|---|
| Size | : 3 Inch |
| Type | : Part C |
| Material | : Brass |
| Vendor Number | : CF1200330 |
A coupler x hose shank connection in 3", built in brass with solid pins.
A coupler x hose shank connection in 3", made and broken by hand. The multi-barbed shank takes a center punch clamp or an interlocked ferrule or sleeve. Brass gives useful corrosion resistance without the price of stainless.
- Size: 3"
- Type: Part C coupler
- Connection: coupler x hose shank
- Material: brass
- Maximum allowable working pressure: 125 psi
- Pressure rating is based on Buna-N seals below 100°F
- Multi-barbed hose shank works with center punch clamps or an interlocked ferrule or sleeve
- Cast, machined and assembled in the USA
- Assembled with solid pins
- Complies with Commercial Item Description A-A-59326D for quick disconnect couplings
- Not rated for compressed gas service, including air and steam
